No.

Technical specification

1

Lid Opening and Closing Device: It adopts a lever - type multi - link synchronous telescopic structure, enabling the lid and the cylinder to open and close flexibly, lightly, safely and reliably.

2

Shell and Chamber Material: The shell is made of a combination of heat - resistant high - quality engineering materials and stainless steel. The sterilization chamber is made of 316 stainless steel.

3

Sealing Ring Structure: Self - expanding sealing ring structure, double - layer jacket type, with water - vapor separation.

4

Control Panel: The control panel adopts an LCD liquid - crystal window for graphic and text display. Function settings are all selected through scrolling graphics and text. The entire sterilization process is displayed graphically and textually by a microcomputer and is automatically controlled by a cyclic program. It automatically shuts down after the sterilization is completed (with an alarm).

5

Sterilization Process Indication: The sterilization process has a dynamic indication, which is convenient for users to observe the working status. Fixed programs can be preset for sterilization mode selection for solids and liquids.

◦ Sterilization Process Mode: Heating → Sterilization → Exhaust (Cooling) → End

◦ Agar Mode: Heating → Melting → End

6

Temperature and Time Setting: The temperature and time setting adopts a one - key operation mode, allowing for quick and clear selection according to different sterilization items.

7

It has a sterilization time reservation function, which is convenient for users to turn on the machine at a set time. The sterilizer can be used for sterilization in multiple fields such as pharmacy, medical treatment, food, chemical engineering, and microbiology, including sterilizing culture media, laboratory equipment (such as glassware, pipettes, etc.), biological samples, etc., to ensure a sterile environment for experiments and avoid interference from microbial contamination on experimental results. It can also sterilize pharmaceutical production equipment, packaging materials, and active pharmaceutical ingredients to ensure the quality and safety of pharmaceuticals and comply with the Good Manufacturing Practice for pharmaceuticals.

8

Steam Inlet Mode: Controlled by a manual valve. Steam is generated by the jacket, and a manual valve controls the steam supply into the sterilization chamber.

9

Safety Devices:

◦ It has a safety interlock function, adopting an electronic - mechanical interactive safety interlock structure to ensure that the lid is automatically locked when there is pressure, avoiding unsafe situations caused by misoperation.

◦ It has a dual - protection system consisting of a mechanical safety pressure - relief valve and an electronically controlled overpressure protection device.

◦ It has a water - break protection against dry - burning and a leakage protection system.

◦ It has a fault automatic detection and judgment system.

10

Sterilization Temperature and Time Range: The selectable setting range for sterilization temperature is 50℃ - 134℃, and the adjustable setting range for sterilization time is 0 - 9999 minutes.

11

It has a verification interface, a double - set protection system consisting of a mechanical safety pressure - relief valve and an electronically - controlled overpressure protection device; a water - shortage protection (anti - dry - burning) and leakage - protection system; and a fault - automatic - detection and judgment system. The machine has pressure control to protect against safety hazards caused by overpressure. It is equipped with a short - circuit protector to prevent electric shock, and the power cord has a grounding wire to prevent electric leakage.

12

Volume: 75 liters, Power supply voltage: 220V/50Hz single - phase power, Power: 5KW (2.5KW * 2)

13

Sterilization chamber dimensions: φ370×600 (mm). Gross weight: 114Kg. Net weight: 110Kg

14

Basket Dimensions: 3 baskets. Diameter * Height: φ330*190mm.

15

Packaging dimensions: 660*780*1320(mm).

Instrument overall dimensions: 600*730*1100(mm).

16

Design pressure of this equipment: 0.24Mpa. Rated working pressure: 0.217Mpa.

17

Special Equipment Pressure Vessel Certificate: It has a special equipment pressure vessel certificate as required by the state.

List of Main Components

Item No.

Description

Specification

Quantity

1

Pressure Switch

1pc

2

Temperature - controlled Probe

PT100

2pcs

3

Solid - state Relay

440V  40A

1pc

4

Air Switch

250V  15A

1pc

5

Electric Heating Tube

2.5KW*2

1pc

6

Safety Valve (Spring - type)

0.24Mpa

2pcs

8

Pressure Gauge

0-0.4Mpa

2pcs

9

Sealing Ring

Silicone

1pc

11

Solenoid Valve

4pcs

12

Drainage Hose

Metal Hose

2pcs

13

Basket

3pcs （335*190）
