Product name：JC-DRH-80Z/160Z/250Z low temperature biochemical incubator (upgrade) -
Order number： -
Model：JC-DRH-80Z/160Z/250Z -
Stock status：Delivery according to contract -
Logistics：4、by sea, by air, by express, etc.
- Product Introduction
-
1.Product introduction
The low temperature biochemical incubator is suitable for environmental protection, agriculture, livestock, aquatic products and other research, college experiments and production departments. It is a special low-temperature equipment for environmental testing.
2. Product parameters
model
JC-DRH-80Z
JC-DRH-150Z
JC-DRH-250Z
volume
80L
150L
200L
Cooling System
Hermetic compressor
cooling method
air cooling
ambient temperature
5～35°
temperature range
-4 0 ~ 50 ℃
temperature resolution
0.1 ℃
temperature uniformity
± 1 ℃
temperature fluctuation
≤±0.5℃ can be increased to 0.1℃ as needed
Heating rate
2 ~ 3 ℃ /min can be increased to above 10 ℃ as needed
Cooling rate
0.7～1℃/min can be increased to above 10℃ as needed
temperature range
30%～98%RH can be customized according to customer requirements
Humidity error
≤ +2 %/-3%RH
noise
≤65dB (national standard is ≤75dB )
power supply
~ 220V 50Hz
Liner size
400×400×500
500×400×750
550×500×900
Dimensions
500×620×1140
600×610×1500
650×710×1650
load carrier
3
3
3
Timing range
1-9999min
Remark
Non-standard sizes can be customized according to customer technical requirements ! The above data are all no-load data!
3. Product Features
1. Microcomputer intelligent controller of low temperature biochemical incubator, with timing, over temperature, over current, power failure, alarm and safety protection functions.
2. International brand compressors and circulating fans, environmentally friendly fluorine-free refrigerants, and a reasonable evaporative condenser system can quickly cool, with high efficiency, low energy consumption and long service life.
3. The low temperature biochemical incubator adopts a double door structure, and the inner door is a tempered glass door, which has good thermal insulation performance. Mirror stainless steel liner, semi-circular arc at four corners, easy to clean inside the box, adjustable shelf.
4. The low temperature biochemical incubator is equipped with an independent temperature limit alarm system, which will be automatically interrupted when the temperature exceeds the limit to ensure the safe operation of the experiment without accidents (optional).
5. The low temperature biochemical incubator has an RS-485 interface, which can be connected to a printer and a computer, and can record the changing state of temperature parameters (optional).
6. A Φ25mm test hole can be set on the left side of the box, which is convenient for experimental operation and temperature measurement (optional).
